Đồng hồ đo độ cứng PCE-DX-DS 0 đến 44.5 N

Mechanical Hardness Tester for measuring hard plastic, with needle
pressure gauge for improved reading of PEAK value

This Hardness Testerr is for measuring the the hardness of the surface (Shore D) of hard rubber and plastic. It is composed of a sensor with an 360º anti-glare dial. The device can be calibrated at anytime, and an ISO calibration certificate can be ordered when required. For a better heading of PEAK value, the device comes with an additional needle that freezes to mark the maximum point. Once the reading has been taken the needle can be reset to zero. With the PCE-DX-DS (D) model, you will always obtain values of the highest accuracy and repeatability.

- With needle pressure gauge
- Read in different hardness units
- 360º dial
- Highly accurate
- Meets all standards
- Comes with a small case
- Optional ISO calibration certificate

View or print the user's manual

PCE-DX-DS Hardness Tester

Technical Specifications

Force of pressure

0 to 44.5 N

Body of penetration

30º (according to Shore D)

Diameter of dial

57mm

Total length

110mm

Range display

0 to 100

Measurement range

10 to 90  (ouside of this range , reduce pressure)

Margin of error

±1

Division of scale

1

Needle pressure guage

yes

Weight

160g

Delivery contents
PCE-DX-DS Shore D Hardness Tester with needle pressure gauge and case
