Đồng hồ đo LCR Lutron LCR-9183 (100Hz - 100KHz)

Model : LCR-9183
Function same as LCR-9184, but without LCD backlight structure, without sorting function and the accuracy will be larger than LCR-9184

FEATURES

*  19,999/1,999countsdualLCDdisplay.

*  AutoLCRsmartcheckandmeasurement.

*  Serial/Parallelmodesareselectable.

*  Ls/Lp/Cs/CpwithD/Q/θ/ESRparameters.

*  SupportDCRmode1.00Ω  to200.0MΩ .

*  Fivedifferenttestfrequencyareavailable: 100Hz/120Hz/1KHz/10KHz/100KHz.

*  TestACsignallevel:0.6Vrmstypically.

*  Testrange:(ex.F=1KHz)L:200.00uHto2000.0H C:2000.0pFto2.000mFR:20.000Ω  to200.0MΩ

*  Multi-levelbatterydetector.

*  RS232/USBPCComputerinterface.

*  Candefaultautopoweroff.

GENERAL  SPECIFICATIONS

Display	LCDsize：56.4X52.9mm.
Testfrequency	100Hz/120Hz/1KHz/10KHz/100KHz
Function	L/C/RFunctionselector FrequencyselectorD/Q/θ  /ESRselector Sortingmodeselector Backlight
Dissipation factor	0.000to999
Qualityfactor	0.000to999
θ measurement	±  90°
Sorting tolerance mode	±0.25%,±0.5%,±1%,±2%,±5% ±10%,±20%,+80%-20%
Calibration	Open/Short  calibration
DataHold	Freezethedisplayreading
Dataoutput	RS232/USB  PCcomputerinterface
Poweroff	Autoshutoffsavesbatterylifeormanualoffbypushbutton
Operating temperature	0℃to50℃
Operating humidity	Lessthen85%R.H.
PowerSupply	006PDC9Vbattery *AlkalineorHeavydutytype
	DC9Vadapterinput *AC/DCpoweradapterisoptional.
Power consumption	DC35mAapproximately
Dimension	193x88x41mm
Weight	420g *meteronly
Standard Accessories Included	*  Instructionmanual.......................1PC *  Alligatorclips(redandblack)......1Pair
Optional Accessories	SMDtester,SMDA-22 SMDtestclip,SMDC-21 Holster,  HS-03 ACtoDC9Vadapter Hardcarryingcase,CA-06 Softcarryingcase,CA-05A

ELECTRICALSPECIFICATIONS  (23±5℃) Resistance(DCR)

Range	Accuracy	Remark
20Ω	±(0.5%+5d)	AfterShortCAL.
200Ω	±(0.5%+5d)
2KΩ	±(0.5%+5d)
20KΩ	±(0.5%+5d)
200KΩ	±(0.5%+5d)
2MΩ	±(0.5%+5d)	AfterOpenCAL.
20MΩ	±(1%+5d)	AfterOpenCAL.
200MΩ	±(2%+5d)	AfterOpenCAL.

Resistance(Rp/Rs)

Range	Accuracy	Accuracy	Remark
	100Hz/120Hz	1000Hz
20Ω	±(1%+5d)	±(1%+5d)	After  ShortCAL.
200Ω	±(0.5%+5d)	±(0.5%+5d)
2KΩ	±(0.5%+5d)	±(0.5%+5d)
20KΩ	±(0.5%+5d)	±(0.5%+5d)
200KΩ	±(0.5%+5d)	±(0.5%+5d)
2MΩ	±(1%+5d)	±(1%+5d)	After  OpenCAL.
20MΩ	±(1%+5d)	±(2%+5d)	After  OpenCAL.
200MΩ	±(2%+5d)	±(5%+5d)	After  OpenCAL.

Range	Accuracy	Accuracy	Remark
	10KHz	100KHz
20Ω	±(1%+5d)	±(2%+5d)	After  ShortCAL.
200Ω	±(0.5%+5d)	±(0.5%+5d)
2KΩ	±(0.5%+5d)	±(0.5%+5d)
20KΩ	±(0.5%+5d)	±(0.5%+5d)
200KΩ	±(0.5%+5d)	±(0.5%+5d)
2MΩ	±(1%+5d)	±(2%+5d)	After  OpenCAL.
20MΩ	±(2%+5d)	-------------------	After  OpenCAL.

Capacitance  (Cp/Cs):D≦0.1

Range	Accuracy	Accuracy	Remark
	100Hz/120Hz	1000Hz
20pF	±(2%+5d)	±(1%+5d)	After  OpenCAL.
200pF	±(1%+5d)	±(1%+5d)	After  OpenCAL.
2000pF	±(0.8%+5d)	±(0.8%+5d)	After  OpenCAL.
20nF	±(0.5%+5d)	±(0.5%+5d)
200nF	±(0.5%+5d)	±(0.5%+5d)
2000nF	±(0.5%+5d)	±(0.5%+5d)
20uF	±(0.5%+5d)	±(0.5%+5d)
200uF	±(0.5%+5d)	±(0.5%+5d)	After  ShortCAL.
2000uF	±(1%+5d)	±(1%+5d)	After  ShortCAL.
20mF	±(2%+5d)	-------------------	After  ShortCAL.

Range	Accuracy	Accuracy	Remark
	10KHz	100KHz
20pF	±(1%+5d)	±(1%+5d)	After  OpenCAL.
200pF	±(0.5%+5d)	±(0.5%+5d)	After  OpenCAL.
2000pF	±(0.5%+5d)	±(0.5%+5d)	After  OpenCAL.
20nF	±(0.5%+5d)	±(0.5%+5d)
200nF	±(0.5%+5d)	±(0.5%+5d)
2000nF	±(0.5%+5d)	±(0.5%+5d)
20uF	±(0.8%+5d)	±(0.8%+5d)
200uF	±(1%+5d)	-------------------	After  ShortCAL.

Inductance  (Lp/Ls):D≦0.1

Range	Accuracy	Accuracy	Remark
	100Hz/120Hz	1000Hz
20uH	±(1%+5d)	±(1%+5d)	After  ShortCAL.
200uH	±(1%+5d)	±(1%+5d)	After  ShortCAL.
2000uH	±(0.8%+5d)	±(0.8%+5d)
20mH	±(0.5%+5d)	±(0.5%+5d)
200mH	±(0.5%+5d)	±(0.5%+5d)
2000mH	±(0.5%+5d)	±(0.5%+5d)
20H	±(0.5%+5d)	±(0.5%+5d)
200H	±(0.5%+5d)	±(0.8%+5d)
2000H	±(1%+5d)	-------------------	After  OpenCAL.

Range	Accuracy	Accuracy	Remark
	10KHz	100KHz
20uH	±(1%+5d)	±(1%+5d)	After  ShortCAL.
200uH	±(0.8%+5d)	±(0.8%+5d)	After  ShortCAL.
2000uH	±(0.5%+5d)	±(0.5%+5d)
20mH	±(0.5%+5d)	±(0.5%+5d)
200mH	±(0.5%+5d)	-------------------
2000mH	±(0.5%+5d)	-------------------

* Appearance and specifications listed in this brochure are subject to change without notice
